Phacoemulsification

• Frequency 29 KHz
• Four crystal titanium handpiece
• Stroke length 100 micron max
• Ultrasonic power 5-100% in 5% increments
• Monitors effective phaco time
• Independently adjustable vaccum and flow limits
• Ultrasonic modes : Linear, Pulse, Auto Pulse
  Micro Pulse (1-100 Pulses / second, 10-90% duty cycle).
  Hyper Burst (4-600ms changable burst width), Auto Burst and panel Phaco Power

Diathermy

• Bipolar wet-field coagulation
• Operation frequency 1.00 MHz
• Electrical power 10 W at 100 E
• Diathermy power 5-100% in 5% increments
• Linear and panel power
• Output short circuit protected

Vitrectomy

• Pneumatically driven guillotine type
• 60 to 1200 cuts/min in 60 cuts/min increments
• Controllable in linear and panel mode
• Independently adjustable vacuum and flow limits

General

• Dimensions [W x H x D] 200 x 250 x 180 mm
• Console weight 4 Kg approx
• Foot Pedal weight 2.7 Kg approx
• Supply voltage 90-265 V AC, 50-60 Hz
• Power consumption 90 W max

Aspiration

• Peristaltic Pump
• Vacuum 5-600 mmHg in 5 mmHg increments
• Pump flow 1-50 cc/min in 1 cc/min increments
• Linear and panel mode for vacuum and aspiration
• Audio feedback for irrigation, aspiration and occlusion

Irrigation

• Gravitational. Regulated by bottle height from 30 to 120 cm.
